KAROSERI

PERFORMA

Kecepatan Maksimum km/h 99
Daya Tanjak tan % 53
Model - E13C-BJ
Model Tipe - Mesin Diesel 4 Langkah Segaris; Direct Injection; Variable Nozzle Turbo; Turbo Charger Intercooler, Common Rail
Tenaga Maksimum PS/rpm 410 / 1.800
Daya maksimum Kgm/rpm 204 / 1.100
Jumlah silinder - 6
Diameter x Langkah Piston mm 137 x 146
Isi Silinder cc 12.913
Tipe - Single Dry Plate with Damper Spring
Diameter Cakram mm 430
Tipe - ZF 16S2530
Ke-1 - 13.804 / 11.539
Ke-2 - 9.487 / 7.930
Ke-3 - 6.529 / 5.458
Ke-4 - 4,565 / 3,816
Ke-5 - 3,023 / 2,527
Ke-6 - 2,078 / 1,737
Ke-7 - 1,430 / 1,195
Ke-8 - 1,000 / 0,835
Mundur - 12,923 / 10,803
Tipe - Intergral Power Steering Recirculating with Hydrolic Booster
Minimal Radius Putar m 13,5
Depan - Reversed Elliot, "I" section
Belakang - Full Floating Type Spiral Bevel Gear with Hub Reduction
Perbandingan Gigi Akhir - 5.410
Sistem Penggerak - Rear 8x4
Rem Utama - Full Air with Dual Circuit (ABS Without ASR)
Rem Pelambat - Engine Retarder, Transmission Intarder
Rem Parkir - Wheel Parking, F2 & R1,R2 Axle
Ukuran Rim - 24 x 8.50 -180
Ukuran Ban - 12.00-R24-18PR
Jumlah Ban - 12 (+1)
Accu V-Ah 12V - 120Ah x 2
Kapasitas L 330
Jarak Sumbu Roda WB (mm) 1.850 + 3.750 + 1.500
Total Panjang OL (mm) 9.290
Total Lebar OW (mm) 2.545
Total Tinggi OH (mm) 3.205
Lebar Jejak Depan FR Tr (mm) 2.065
Lebar Jejak Belakang RR Tr (mm) 1.870
Julur Depan FOH (mm) 1.400
Julur Belakang ROH (mm) 790
Kabin Kesumbu Roda Belakang CA (mm) 5.190
Depan & Belakang - Semi elliptical; Multi Leaf Spring with Shock Absorber & Stabilizer & Semi-elliptical; Multi Leaf Spring with Stabilizer & torque rod
Depan kg 11.860
Berat Total Kendaraan kg (GVW) 50.000
